APPLICATIONS

With the burgeoning New Space market, our products have found their place in numerous LEO applications, launchers, and even on the moon. We analyze your specific requirements and recommend the most suitable product to ensure mission success.

We provide a Linux Software Development Kit (SDK) based on industry-standard toolchains, enabling our customers to implement their designs on our boards rapidly. We also offer a Vivado skeleton project as a starting point, leaving over 90% of the FPGA resources available for your application.

Absolutely! We collaborate closely with our customers to cater to varied interface requirements. We either provide a ready solution or guide your team on how to implement it.

Yes, we do: Our technical support aims to assist with product understanding and overcoming initial learning curves. We also provide project-specific support packages, which can be utilized to develop custom software or logic, review your design, or even aid in designing your carrier board.

We quantify radiation exposure through testing of both Total Ionizing Dose (TID), which accumulates over time, and Single-Event Effects (SEE), which is more like a lightning strike. TID is a measure of the total amount of radiation that a device is expected to be exposed to over its mission life, while SEE is a measure of the effects of the individual "hits" of radiation that a device has experienced.

The board has dual FPGA (processor and supervisor) and ECC for its memory banks. It also provides a suite of other radiation effects mitigation features. We also ensure that the selected components can survive the harsh radiation environment of space.

Xiphos provides memory scrubbing software that can be run in the background of the main application software to clear single-bit errors in memory.

Xiphos conducts a radiation qualification test campaign, including board-level proton and TID (gamma ray) testing, as well as an environmental qualification that includes TVAC, vibration, and shock testing.

We provide spec sheets, pinout files, user manuals, mechanical drawings, and 3D STEP files, some of which are provided under NDA.

The document lists various Processor Boards with their specifications, like the Q7, Q7AE, Q7RH, Q8, Q8J, Q8RF, and Q8RH.

For Q7, there's the Q7ACS and Q7 Camera Board. For Q8, there's the Q8 Camera Board, Q8 SDR Dock, and Q8 DHMMU.

The Q7 MPSoC FPGA has multiple ‘hard core” peripherals, including 2x Gigabit Ethernet MAC, 2x USB 2.0, 2x CAN 2.0B, 2x SDIO, 2x SPI, 2x UART, 2x I2C, GPIO. For Q8, there's PCI Express 2.1, SATA 6Gbs rev 3.1, 4x Ethernet MAC rev 2.0, and 2x USB rev 2

The Q8 and Q8J MPSoC FPGAs have multiple ‘hard core” peripherals, including 4x Gigabit Ethernet MAC, 2x USB 3.0/2.0, 2x CAN 2.0B, 2x SDIO, 2x SPI, 2x UART, 2x I2C, GPIO, PCI Express (PCIe) Gen 2, and SATA 6Gbs Rev 3.1. The Q8J also provides access to the MPSOC’s 2x PCIe Gen 3 cores in the PL.

Xiphos creates superior, high-performance, space-ready COTS-based Processor Boards and Daughterboards, leveraging the power of Xilinx MPSoC FPGAs.

Quite a lot!

• Exceptional performance: Our products are built to deliver unparalleled performance in the most challenging applications.
• Flight-proven resilience: Rigorous testing under the harshest conditions ensures the reliability of our products.
• Tailored solutions: We offer customization to cater to your specific needs.
• Comprehensive support: Our wide range of support options will ensure you get the maximum value out of our products.

• Processor Boards: The beating heart of our product line, our Processor Boards come packed with various features and options to cater to diverse applications.
• Daughterboards: Our Daughterboards are compact and specialized, designed for particular applications such as SDR, imaging, or robotics.
• Software: We provide a suite of software tools to aid you in developing and deploying various applications on our products.

Xiphos' products can be accessed through multiple channels, including this website, authorized distributors, and direct sales representatives.
